Lentes | f=4.0 mm F 1.8 Board lens Dual-band Fixed IR corrected |
Campo de vision | 71° (horizontal) 52° (vertical) 90° (diagonal) |
Tiempo de obturacion | 1/5 ~ 1/15,000 sec. |
Sensor de imagen | 1/4" CMOS in 640 x 480 Resolution |
Iluminacion minima | 0.001 Lux @ F1.8 ( Color ) |
Iluminadores IR | IR LED*12 Built-in IR illuminators, Effective up to 10 meters |
Video | Compression: H.264, MPEG-4 & MJPEG Streaming: Simultaneous dual streams H.264 streaming over UDP, TCP, HTTP or HTTPS H.264/MPEG-4 multicast streaming MPEG-4 streaming over UDP, TCP, HTTP or HTTPS MJPEG streaming over HTTP or HTTPS Supports 3GPP mobile surveillance Frame rates: H.264: Up to 30/25 fps at 640x480 MPEG-4: Up to 30/25 fps at 640x480 MJPEG: Up to 30/25 fps at 640x480 |
Configuracion de imagen | Adjustable image size, quality, and bit rate Time stamp and text caption overlay Flip & mirror Configurable brightness, contrast, saturation, sharpness, white balance and exposure control AGC AWB AES Automatic, manual or scheduled day/night mode Supports privacy masks |
Redes | 10/100 Mbps Ethernet, RJ-45 ONVIF support Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS and 802.1X |
Alarma y gestion de eventos | Triple-window video motion detection 1 D/I for external sensor and alarm Event notification using HTTP, SMTP, FTP Local recording of MP4 files Tamper Detection |
Seguridad | Multi-level user access with password protection IP address filtering HTTPS encrypted data transmission 802.1X port-based authentication for network protection |
Usuarios | Live viewing for up to 10 clients |
Dimensiones | Width: 150mm Ø: 60mm; Cable length: 400 mm Cable diameter: Ø 12 mm; Max. Connector: Ø 18 mm |
Indicador LED | System restore status indicator |
Energia | 12V DC 24V AC Power consumption: Max. 4 W 802.3af compliant Power-over-Ethernet (Class 2) |
Viviendas | Weather-proof IP66-rated housing |
Aprovaciones | CE C-Tick FCC LVD VCCI |
Entornos operativos | Temperature: -20 ~ 50 °C (-4 ~ 122 °F ) Humidity: 90% |
Viendo requerimientos del sistema | OS: Microsoft Windows 7 / Vista / XP / 2000 Browser: Mozilla Firefox Browser: Internet Explorer 7.x or above VLC: 10.5 or above QuickTime: 6.5 or above Cell phone: 3GPP player Real Player 10.5 or above |
Gestion de instalacion y mantenimiento | Installation Wizard 2 ST7501 32-channel recording software Supports firmware upgrade |
Aplicaciones | SDK available for application development and system integration |
Garantia | 24 Months |
