Ampliar GV-Data Capture es un dispositivo que conecta un sistema de vigilancia digital de Geovision, un DVR basado en PC, a un sistema de punto de venta electrónico. Está diseñado para ser instalado entre un sistema GV y un sistema de punto de venta, a través de puertos COM de PC.
| Specifications | ||
| Input | RS-232 from POS Parallel Port from POS | DB9 Female DB25 Male |
| Output | RS-232 to Printer Parallel Port to Printer RS-232 Port to DVR RS-485+ RS-485- | DB9 Male D B25 Female DB9 Female Connect to GV-NET RS-485+ Connect to GV-NET RS-485- |
| Communication | RS-232 from POS Parallel Port from POS RS-232 to DVR RS-485 to GV-NET or GV-NET Card | 1,200bps~115,200bps SPP / Normal 1,200bps~115,200bps 1,200bps~19,200bps |
| DC IN | Power Adapter DC 5V, 2A Inner Positive | |
| Environmental Conditions | Operation temperature Humidity | 0~50 degree C5%~95% (non-condensing) |
| Dimensions | 161 (W) x 34 (H) x 123 (D) mm | |
